SHARP GF-305ST Stereo Radio Cassette Boombox
1 in stock
SHARP GF-305ST
FUTURES:
- Manufactured Date: 1978 of September
- 2-way speaker system 16 cm woofers, 5 cm tweeters
- 12 watts output power (2 × 6 W)
- Analog VU level meters
- Dual telescopic radio antennas
- Metal cassette door
- Headphone output
- External microphone input
- External speaker connections
- Line output connection
Available colors:
- Silver
- Black
849.00€
1 in stock
The Sharp GF-305 was a high-end Japanese-market stereo boombox introduced in 1978 as an upgraded version of the GF-303. It was part of Sharp’s early “The Searcher” series. The GF-305 is considered one of Sharp’s most desirable late-1970s “Searcher” models because of its excellent sound quality, variable tape-speed feature, and relatively compact size compared with later giant Sharp boomboxes.
SPECIFICATIONS
Power source: A.C. 100V, 50/60Hz 14W D.C. 15V (Ten UM/SUM-1, R20 batteries or external D.C. supply)
Speakers: 16cm (Woofer) х 2; 5cm (Tweeter) х 2
Output power: 12W(6W+ 6W) EAIJ/DC15V
Semiconductors: 6-ICs (Integrated circuit) ,FET-2, 33-Transistors 24-Diodes 3-LEDs
Dimensions: Width x 516mm, Depth x 115mm, Height x 271mm
Weight: 7.8kg (With batteries)
TAPE RECORDER SECTION
Tape: Philips type compact cassette tape
Frequency response: 50 ~15000Hz (CrO2 tape)
50 ~12000Hz (normal tape)
S/N ratio: 50dB
Wow &flutter: 0.09% WRMS
Input sensitivity and input impedance: Microphone; 600 ohms
Mixing mic.; 600 ohms
Output level and loaded impedance: Headphones; 4 to 8 ohms
External speaker; 4 to 8 ohms
Line out; 0.7V/50k ohms
RADIO SECTION
Frequency Range: AM; 530~1605kHz AM 455kHz
FM; 76-108MHZ FM:10.7MHz
Video
Soon!
There are no reviews yet.
