National RX-5650
NATIONAL RX-5650 Stereo Radio Cassette Recorder
Availability:
1 in stock
NATIONAL RX-5650
FUTURES:
- Manufactured Date 1981 of April
- Metal Tape Compatible
- Built-in Dolby NR Circuit To Reduce Tape His Noise
- Equipped with an Upright Perspective Soft Touch Mechanism
- 3 Song TPS (Tape Program Sensor) Function
- Current Design That Emphasizes Sound Quality To Enjoy Powerful Sound
- Powerful Quality Design With Sound Powerful Sound
- A Book To Which An MM Cartridge Radar Player Can Be Connected With A Fono Terminal With a Built-In Equalizer Amplifier
- Built-in Triple Mixing (Recording/Playback) Circuit
- Listen To The Audio Of TV Broadcasting (1-3 Channels) Id Band (76~108MHz) Adopted
- With Switch For Manual Recording/Automatic Recording
- 4-Way Large High-Precision Needle Type Meter
- 3 Power Supply System Adopted
Available colours:
- Silver
1,049.00€
1 in stock
The National RX-5650 is a stereo radio and cassette recorder manufactured in Japan (brand: National, which is a Panasonic / Matsushita brand) circa early 1980s. It’s one of the larger boomboxes of its era, featuring multiple speaker drivers, Dolby noise reduction, and support for “metal tape” (high-bias cassette) in addition to more common tape types. Some listings refer to it also as National / Technics RX-5650, highlighting its premium / hi-fi aspirations. It seems to have been positioned as a “sound quality” model, with emphasis on powerful audio, wide frequency response with the right tapes, and flexible input/output capabilities.
RADIO FREQUENCY RANGE: FM (76-108 MHz)
AM (525-1605 kHz)
Intermediate frequency: FM 10.7 MHz, AM 455 kHz
Sensitivity: FM 1μV/m 50mW (S/N 6db), AM 70 μV /m / 50mW
POWER REQUIREMENT: AC 100V(90˜110 V),50/60Hz
Power consumption: 15 W Battery; 12 V (8-UM-1, “D” size batteries) DC in 13.2V Car battery; with optional car battery cord RP-957A
POWER OUTPUT: 10 W (5 Wx2) (EIAJ/DC.)
SPEAKERS:
Woofer: 16cm x 2 PM dynamic speaker 3Ω
Tweeter: 5cm PM dynamic speaker 4Ω
FREQUENCY RANGE:
40-12,000 Hz (with normal tape)
40-14,000 Hz (with FeCr tape)
40-14,000 Hz (with tape corresponding to CrO2 type)
40-17,000 Hz (with Metal tape)
Wow & Flutter: 0,055%(WRMS)
RECORDING SYSTEM: AC bias, AC erase
TAPE SPEED: 4.8cm/s.
PROGRAM TIME: 1 hour with C-60 cassette tape
Fast Forward and Rewind Time: Approx 90 seconds With C-60 cassette tape
TRACK SYSTEM: 4-track 2-channel stereo recording and playback
JACKS:
INPUT: MIC: sensitivity 0.25 mV/applicable microphone impedance 200Ω-600Ω (recommended microphone RP-8135)
MIX MIC: Sensitivity 0.8 mV/applicable microphone impedance 200-600Ω
LINE IN: Sensitivity 130 mV/47 kΩ over
PHONO: Sensitivity 3.9 mV/47 kΩ over
OUTPUT:
LINE OUT: Sensitivity 0.42 V/2.2kΩ under
EXT SP: 3-8Ω
HEADPHONES: 8Ω
OTHERS: DC IN: 13.2V (12-15 V) AC IN Ext Antenna and Earth, Phono Earth
DIMENSIONS: 563 mm (W) x 325 mm (H) x 140 mm (D)
WEIGHT: 7.6kg without batteries
